ZBOX CI337 nano (Barebone)
The ZBOX CI337 nano features a power-efficient next-generation Intel N-Series processor to give you a silent experience in a compact PC. A robust, passive cooled design with no moving components brings high reliability and extended durability. The signature honeycomb vents throughout the chassis enhances exhaust flow, backed by a large aluminum heatsink that maximizes heat transfer from the CPU to keep the system operating with continued performance.
- Passively cooled for silent performance
- Intel Processor N100
- 1 x M.2 PCIe 3.0 x1/SATA SSD slot (2242), 1 x 2.5-inch HDD/SSD bay
- Up to 16GB DDR5 SO-DIMM memory support
- Windows 11 Ready
- 4K@60 Hz ready with HDMI 2.0b, DisplayPort 1.4 and DisplayPort via USB-C
- 4 x USB 3.2 ports (1 Type-C)
- Dual Gigabit Ethernet, Wi-Fi 6 and Bluetooth 5.2
- VESA Mount Ready
- Palm-sized, 0.9L chassis
Computing System |
|
| Processor | Intel Processor N100 (quad-core 0.8 GHz, up to 3.4 GHz) |
| Chipset | Intel |
| System Memory | 1 x DDR5-4800 SODIMM Slot (up to 16GB) |
Graphics |
|
| Graphics Engine | Intel UHD Graphics (Integrated) |
| Video Output | 2 x HDMI 2.0 (up to 4096x2160 @ 60Hz) DisplayPort 1.4 (up to 4096x2160 @ 60Hz) DP via USB-C (up to 4096x2160 @ 60Hz) max 3 displays |
Storage |
|
| Hard Drive | 1 x 2.5-inch SATA 6.0 Gbps SSD/HDD slot |
| Mass Storage | N/A |
| Optical Drive | N/A |
| mSATA | N/A |
| M.2 | 1 x M.2 PCIe 3.0 x1 / SATA SSD slot (2242) |
| Card Reader | 3-in-1 (SD/SDHC/SDXC) |
I/O Ports |
|
| Audio | Microphone in Audio out 8-ch Digital Audio via HDMI |
| USB Port | 1 x USB 3.2 (Front) 1 x USB 3.2 Type-C (Front) (Supports DP output) 2 x USB 3.2 (Rear) |
| LAN | 2 x 10/100/1000Mbps |
| Antenna | External |
| WiFi | WiFi 6 |
| Bluetooth | Bluetooth 5.2 |
| Legacy I/O | N/A |
| CIR Infrared | N/A |
| Expansion | N/A |
| USB | N/A |
| IDE | N/A |
| VGA | No |
Mechanical |
|
| Kensington Lock | Yes |
| LED Indicators | Power, HDD, WiFi |
| Power Supply | AC Adapter O/P: DC 19V/40W |
| Cooling System | Passive cooling |
| ZBOX Dimensions | 127.8mm x 126.8mm x 56.8mm (5.31in x 4.99in x 2.24in) |
| Case Mounting | VESA Mount ready |
Miscellaneous |
|
| Supported OS | Windows 11 ready |
| Accessories | 1 x WiFi antenna 1 x AC adapter 1 x Power cord (bundled cable type dependent on region) 1 x Warranty card 1 x Quick Install Guide 1 x VESA Mount (with 4 screws) |
