ZBOX pico PI430AJ with AirJet (Barebone)
The ZBOX pico PI430AJ with AirJet is the world’s first mini PC to incorporate Frore Systems‘ AirJet Solid State Active Cooling chip, which generates rapid airflow without fans. The more robust cooling hardware allows the PI430AJ to be equipped with more capable hardware, such as an Intel Core i3 CPU, 8GB LPDDR5 fast memory, and a full-fledged M.2 NVMe SSD, all while impressively staying the size of a deck of playing cards.
Feature Highlights
- World’s first Solid State Active Cooling Mini PC
- Whisper quiet operation
- Ultra-compact 0.21 Liter design, VESA Mount Ready
- 4K@60 Hz ready with HDMI 2.0 and DisplayPort 1.4
- Intel Core i3-N300 processor
- 8GB LPDDR5 Onboard Memory
- M.2 NVMe SSD Slot
- 3 x USB 3.2 Ports (1 Type-C)
- WiFi 6, Gigabit Ethernet and Bluetooth 5.2
- Windows 11 Ready
Computing System |
|
| Processor | Intel Core i3-N300 processor (8-core, 0.8 GHz, up to 3.8 GHz) |
| Chipset | Intel |
| System Memory | 8GB LPDDR5 onboard memory |
Graphics |
|
| Graphics Engine | Intel UHD Graphics (Integrated) |
| Video Output | HDMI 2.0 (up to 3840x2160@60Hz) DisplayPort 1.4 (up to 4096x2160@60Hz) DP1.4 via USB-C (3840x2160 @ 60Hz) Triple Display Ready |
Storage |
|
| Hard Drive | N/A |
| Mass Storage | N/A |
| Optical Drive | N/A |
| mSATA | N/A |
| M.2 | 1 x M.2 NVMe PCIe 3.0 x4 / SATA SSD slot (2230, 2242, 2280) |
| Card Reader | Micro SDHC/SDXC |
I/O Ports |
|
| Audio | 1 x Headphone/microphone combo jack |
| USB Port | 3 x USB 3.2 (1 Type-C) |
| LAN | 10/100/1000 Ethernet |
| Antenna | Internal |
| WiFi | WiFi 6 |
| Bluetooth | Bluetooth 5.2 |
| Legacy I/O | N/A |
| CIR Infrared | N/A |
| Expansion | N/A |
| USB | N/A |
| IDE | N/A |
| VGA | N/A |
Mechanical |
|
| Kensington Lock | N/A |
| LED Indicators | N/A |
| Power Supply | AC Adapter O/P: DC 5V/5A |
| Cooling System | Solid State Active Cooling |
| ZBOX Dimensions | 114.8mm x 76mm x 23.8mm (4.52in x 2.99in x 0.94in) |
| Case Mounting | Mounting Bracket |
Miscellaneous |
|
| Supported OS | Windows 11 Ready |
| Accessories | Universal Power Adapter with Multiple Plugs Mounting bracket 2 x Mount screws CTIA / OMTP adapter Warranty Card Quick Install Guide USB drive with drivers |
