SPECIFICATIONS

PUMP

Speed: PWM 1500~3300 R.P.M
Rated Voltage: 12 V & 5V
Rated Current: 0.43 A & 0.32 A
Power Input: 5.16 W & 1.6 W
Connector: 2510-4 Pin / 5V ARGB header-3 Pin

WATER BLOCK

FAN

Dimension: 120 × 120 × 25 mm
Speed: PWM 500~2000 R.P.M
Noise Level: 25.8 dB-A
Rated Voltage: 12 V & 5V
Rated Current: 0.11 A & 0.31 A (one fan)
Power Input: 1.32 W & 1.55 W (one fan)
Max. Air Flow: 57.05 CFM
Max. Static Pressure: 2.23 mm-H2O
Connector: 2510-4 Pin PWM, 5V ARGB header-3 Pin
Bearing Type: Hydraulic Bearing
Life expectation: 40,000 hrs, 25°C

TUBE

Length: 460 mm
Material: Rubber

RADIATOR

Dimension: 396 × 120 × 27 mm
Material: Aluminum

COMPATIBILITY

Intel:
LGA 2066
LGA 2011
LGA 1851
LGA 1700
LGA 1200
LGA 1156
LGA 1155
LGA 1151
LGA 1150

AMD:
AM5
AM4
AM3+
AM3
AM2+
AM2

User Manual (Downlaod)
